High-pressure and cleaning nozzles

RANGE OF APPLICATIONS

We would like to present our high-pressure nozzles for cleaning and unclogging drains. Our products are made of high-alloy stainless steel which, due to heat treatment, achieves very high strength and durability.

Every nozzle manufactured by our company has removable ceramic inserts characterised by a high abrasion resistance. Their use greatly expands the life of cleaning nozzles.

Cleaning and rinsing sediments out of the sewer bottom
  • Lower jet nozzle DD

    EXCELLENT COLLECTING DEPOSITS FROM THE BOTTOM OF THE CHANNEL

    Highly effective cleaning of the sewer bottom. Removing and rinsing heavy sand and stone deposits by transferring all the cleaning power to the bottom of a sewer

  • Pulling and rinsing nozzle DC

    GREAT BREAKING POWER, LOW WEIGHT

    Quick removal of debris due to good pulling and rinsing properties. Low deadweight.

  • Rinsing nozzle "FLOUNDER" F

    EXCELLENT PROPERTIES OF COLLECTING SEDIMENTS FROM THE SEWER BOTTOM

    Nozzles for cleaning sewer bottoms. Effective rinsing of heavy sand and stone deposits due to transferring all the power of cleaning to the bottom of a sewer.

  • Rinsing nozzle "Grenade" G

    EXCELLENT PROPERTIES OF COLLECTING DEPOSITS FROM THE SEWER BOTTOM

    Powerful rinsing of sand and gravel contaminants. Removal of sediments from the sewer bottom. Recommended for cleaning sewer systems before TV inspection.

Removing blockages
  • Piercing nozzle "QUATTRO" DQ

    PIERCING, BREAKING BLOCKAGES

    A piercing nozzle that breaks blockages. Very strong forward impingement water jets. Direct entrance into a blockage and its quick removal.

  • Piercing nozzle DP

    PIERCING, BREAKING BLOCKAGES

    Piercing nozzle. Quick and effective breaking and removing of blockages. Very strong forward impingement water jets; very strong backward motive water jets.

  • Super Quattro nozzle DSQ

    Piercing nozzle, crushing blockages

    Piercing nozzle, crushing blockages. Very strong impingement water jets and elongated sharp bevelled edges provide high efficiency of unblocking completely clogged sections.

Removing grease
  • Aluminium nozzle DAL

    EFFECTIVE REMOVAL OF GREASE DEPOSITS

    Removing heavy grease buildups. Strong water outflows that evenly attack the entire section of a pipe.

  • Extensive cleaning nozzle DDC

    GREASE REMOVAL, ENVELOPING CLEANING

    Effective cleaning of pipes by removing grease, hard calcium sediments, and thorough enveloping cleaning.

  • Special nozzles HRH, KBR, RGS

    ROTARY, ENVELOPING CLEANING OF THE ENTIRE SURFACE OF A SEWER

    A group of special nozzles with a central rotary part. Removal of sand, calcium sediments, grease. Even cleaning of the entire pipe section.

Universal nozzles – enveloping cleaning, removing sediments
  • Conical nozzle KS

    GREAT RINSING POWER

    Excellent rinsing of debris due to strong backward water jets. Removal of sand dirt and sediments.

  • Heavy rinsing nozzle"BOMB" BA

    BREAKING BLOCKAGES, GREAT FORCE OF PERCUSSION

    This nozzle is used for rinsing all kinds of contaminants from sewer pipes if the diameter of Ø200 and larger. The nozzle is recommended for pre-rinsing of a sewer before using milling nozzles.

  • Rinsing nozzle KJ

    GREAT RINSING POWER

    Excellent rinsing of contaminants due to strong backward water jets. Removal of sand and thick dirt. Enveloping cleaning.

  • Rinsing nozzle PN

    EXCELLENT ENVELOPING CLEANING OF A SEWER

    Strong backward water jets at large angles. Perfectly cleans sewer pipes in the entire system. Great thrust. Enveloping cleaning.

  • Sewer nozzlea DK

    OVOID SHAPE, GREAT BREAKING AND RINSING POWER

    Strong backward water jet directed at 2 different angles alternately. Used for quick removal of blockages, sludge and other sediments.

  • Spherical rinsing nozzle KK

    ROUND SHAPE, GREAT RINSING POWER

    Large feed of a nozzle with simultaneous strong impingement forward water jet. Removing sand dirt and hard sediments. Enveloping cleaning.

Sewer device (general cleaning)
  • Sewer device "MOLE" KR

    RINSING NOZZLE, ENVELOPING CLEANING OF A SEWER PIPE

    Central location enabling the effective cleaning of the entire perimeter of a sewer. Excellent for cleaning heavy sand and stone sediments.

Removing hard calcium deposits, removing roots, milling of drains before trenchless renovation
  • Chain nozzle DL 200-350

    CUTING ROOTS, MILLING OF HARD DEPOSITS

    Cutting roots and removing calcium sediments and grease in pipes with the diameter of Ø200 and Ø350 mm. High rotary speed of cutting elements.

  • Chain nozzle with teeth DLF 200-450

    CUTTING ROOTS, MILLING HARD DEPOSITS

    For cutting roots and removing hard calcium sediments in pipes with the diameter of Ø200–Ø450 mm. Available in a set with: a saw chain, milling discs, cutting knives.

  • Milling nozzle DF 500-800

    CUTTING ROOTS, MILLING HARD DEPOSITS

    Removal of hard calcium sediments, grease and other contaminants. Effective cutting of roots in heavily overgrown sewers.

  • Rotary nozzle DR 150-200

    CUTING ROOTS, MILLING OF HARD DEPOSITS

    Cutting roots and removing calcium sediments and grease in sewer laterals and pipes with the diameter of Ø150 and Ø200 mm. High rotary speed of cutting elements.
